GSAF11A5D005V063
Product Model:GSAF11A5D005V063
Interface:Female connectors
Input:100V-240V
Output:5V/1A+5V/11.5A
Power:62.5W
Dimension:130*155*31mm
Weight:302g
Output Characteristics:5V/1A;5V/11.5A;12V/1A
Protect Function:open-loop overvoltage protection,overcurrent protection,overvlotage protection,overtemperature protection
Applicable Environment:used for shared power cabinet and works under 0-40℃ environment
Certification Scope:Obtained CE,CB,CQC certificates bundled with shared power cabinet together
Product Introduction

1.The 5V main output can charge for 6 channels power bank;

2.The 5V main output can be used for driving motors after raised voltage to 12V by DC-DC booster

3.Provide independent 5V/1A output for system power supply.
